1U 450mm Short Depth Rack Chassis | Compact 19” rack case for edge server & network appliance
Application
Firewall, router, edge computing host, small NAS, industrial gateway, mini monitoring server, embedded control equipment.
Features*1U rackmount design,meets EIARS-310C standard.
*2 x 3.5" HDD drive bays and 2 x 2.5" drive bays
*Support MAX 12 x 9.6" motherboard
*Support 4 x 40mm fans on the middle
*Two front accessible USB port,2 x USB3.0
*Smooth border prevent lacerating your skin
Specification
| Dimensions ( W x D x H ) |
436mm x 450mm x 43.6mm |
| M/B Form Factor |
Supports ATX (12"x9.6"), Micro ATX (9.6" x 9.6"), Mini ITX (6.7" X 6.7") motherboard |
| Drive Configuration |
2 x 3.5" HDD drive bays and 2 x 2.5" drive bays |
| Power Supply Form Factor |
Standard 1U power supply,1U 1+1 redundant power supply |
| Cooling System |
Support 4 x 40mm fan |
| Expansion slot |
Support 1 full-hight horizontally mounted PCI cards |
| Front panel control |
Power ON/OFF x 1, System reset x 1, USB3.0 x 2 |
| Indicator |
Power ON/OFF x 1, HDD x 1,Nic x 2 |
| Materials |
SGCC 1.2mm |
| Packaging |
Double strenthen carton with EPE foam |
| Carton size |
560*526*155mm |
| Volume |
0.046 CBM |
| Net Weight |
5.4 kg |
| Gross Weight |
7.5 kg |
| Operation Temperature |
-5°--- 45° |
| Storage Temperature |
-40°---70° |
| Humidity |
10% – 90% relative (non-condensing) |
