| Dimensions ( W x D x H ) | 434 x 580 x 200 mm |
| M/B Form Factor | Support EEB(12x13"),ATX(12x9.6"),Mini-ATX(11.2x8.2"), Micro-ATX(9.6x9.6") and ITX motherboard |
| Drive Configuration | Support 9x5.25" ODD trays or change it into 15x3.5" HDD trays Support 4x2.5" SSD trays internal |
| Power Supply Form Factor | Support ATX power supply |
| Cooling System | 4x12025 fan and 2x8025 fans on rear |
| Expansion slot | 7 x PCI slot(support full hightness cards) |
| Front panel control | Power ON/OFF x 1, System reset x 1,USB2.0 x 2 |
| Indicator | Power x 1, HDD x 1,Nic x 2, Power Alarm x1 |
| Materials | SPCC 1.2mm |
| Packaging | Carton with EPE foam |
| Carton size | 745 x 555 x 315mm |
| Volume | 131 CBM |
| Net Weight | 15 KG |
| Gross Weight | 20.2 KG |
| Operation Temperature | -5°--- 45° |
| Storage Temperature | -40°---70° |
| Humidity | 10% – 90% relative (non-condensing) |
